600V Thermoplastic Elastomer TPE Data Transmission Cable UL20842, UL21381, UL21183, UL21557 Shielding Optional

Name: 600V Thermoplastic Elastomer TPE Data Transmission Cable UL20842 UL21381 UL21183 UL21557 Shielding Optional
Brand: WCH Cable
Price: 0.10 USD

China 600V Thermoplastic Elastomer TPE Data Transmission Cable UL20842, UL21381, UL21183, UL21557 Shielding Optional wholesale

Brand Name : WCH Cable

Model Number : UL20842

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 1220 meters

Price : USD0.10 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000000 meters per month

Delivery Time : 9 days for ready goods

Packaging Details : 305 meters per spool / reel

Conductor : Pure Copper Conductor

Insulation : AWM Material

Rated Voltage : 600V

Jacket Material : Thermoplastic Elastomer TPE

Feature : Data Transmission

Style Number1 : UL20842, UL21381

Shielding : Spiral Wrapped or Braided

Style Number2 : UL21183, UL21557

Contact Now

Approval style number: UL20842

Rated temperature and voltage: 80 deg C, 600 Vac, Cable flame.

Conductor: pure copper wire conductor.

Insulation material: PVC, PP, HDPE, LDPE, SR-PVC, XL-PE, XL-PVC, TPE, FRPE.

Jacket material: Extruded TPE.

Applied standard: Appliance Wiring Material UL 758.

Application: External interconnection of electronic equipment.

Origin: Dongguan, China

Equivalent approval style numbers of 600V Thermoplastic Elastomer TPE Data Transmission Cable:

Approval Style	Temperature	Voltage	Material	Brand
UL 20842	80	600	Thermoplastic Elastomer / TPE	WCH Cable
UL 21381	90	600	Thermoplastic Elastomer / TPE	WCH Cable
UL 21183	105	600	Thermoplastic Elastomer / TPE	WCH Cable
UL 21557	105	600	Thermoplastic Elastomer / TPE	WCH Cable

Parameters of 600V Thermoplastic Elastomer TPE Data Transmission Cable:

Approval Style Number	Cores	Conductor		Insulation Thickness	Nom.Dia	Shield Coverage	Jacket Thickness	Overall Diameter	Conductor Resistance
Approval Style Number	Cores	AWG	No/mm	mm	mm	%	mm	mm	Ω/KM
UL20842	2C	30	7/0.100	0.38	1.10	>=65	1.15	5.00	381.00
		28	7/0.127	0.38	1.20	>=65	1.15	5.30	239.00
		26	7/0.16	0.38	1.30	>=65	1.15	5.40	150.00
		24	11/0.16	0.38	1.40	>=65	1.15	5.70	94.20
		22	17/0.16	0.38	1.60	>=65	1.15	6.10	59.40
		20	21/0.178	0.38	1.80	>=65	1.15	6.50	36.70
		18	34/0.178	0.38	2.10	>=65	1.15	7.10	23.20
		16	26/0.25	0.38	2.40	>=65	1.15	7.70	14.60
UL20842	3C	30	7/0.100	0.38	1.10	>=65	1.15	5.30	381.00
		28	7/0.127	0.38	1.20	>=65	1.15	5.50	239.00
		26	7/0.16	0.38	1.30	>=65	1.15	5.70	150.00
		24	11/0.16	0.38	1.40	>=65	1.15	5.90	94.20
		22	17/0.16	0.38	1.60	>=65	1.15	6.50	59.40
		20	21/0.178	0.38	1.80	>=65	1.15	6.80	36.70
		18	34/0.178	0.38	2.10	>=65	1.15	7.40	23.20
UL20842	4C	30	7/0.100	0.38	1.10	>=65	1.15	5.50	381.00
		28	7/0.127	0.38	1.20	>=65	1.15	5.70	239.00
		26	7/0.16	0.38	1.30	>=65	1.15	6.00	150.00
		24	11/0.16	0.38	1.40	>=65	1.15	6.40	94.20
		22	17/0.16	0.38	1.60	>=65	1.15	7.70	59.40
		20	21/0.178	0.38	1.80	>=65	1.15	7.20	36.70
UL20842	5C	30	7/0.100	0.38	1.10	>=65	1.15	5.70	381.00
		28	7/0.127	0.38	1.20	>=65	1.15	5.80	239.00
		26	7/0.16	0.38	1.30	>=65	1.15	6.00	150.00
		24	11/0.16	0.38	1.40	>=65	1.15	6.40	94.20
		22	17/0.16	0.38	1.60	>=65	1.15	7.00	59.40
UL20842	6C	30	7/0.100	0.38	1.10	>=65	1.15	5.90	381.00
		28	7/0.127	0.38	1.20	>=65	1.15	6.30	239.00
		26	7/0.16	0.38	1.30	>=65	1.15	6.70	150.00
		24	11/0.16	0.38	1.40	>=65	1.15	7.00	94.20
