UL21325 Energy Data Transmission Curly Cable 60C 600V

Brand Name : WCH Cable

Model Number : UL21325

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 200 pieces

Price : USD0.235 per piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200,000 piece per month

Delivery Time : 9 days for ready goods

Packaging Details : 200 pieces per carton

Style Number : UL21325

Conductor Material : Highly pure copper wire strands

Rated Temperature : 60°C

Insulation material : AWM verified materials

Rated Voltage : 600V

Jacket Material : Quality Thermoplastic TPU

Core Assembly : Pair or group twisted

Jacket Thickness : 15 mils minimum

Contact Now

UL21325 Energy Data Transmission Curly Cable 60C 600V

Conductor material: extremely high purity copper wire strands, bare or tinned, optional;

Insulation material: PP, SR-PVC, PE, TPE, TPU, PUR, FRPE, etc;

Internal wires quantity: 2C to 50C twisted;

Jacket material: quality thermoplastic TPU.

Application: energy data transmission;

Curly cable rated: 60°C, 600V.

Style Number Core Quantity Conductor Gauge Conductor Strands Insulation Thickness Insulation Diameter Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm mm mm Ω/KM
UL21325 2C 30 11/0.08 0.76 1.90 0.38 5.80 381.00
2C 28 16/0.08 0.76 2.00 0.38 6.10 239.00
2C 26 26/0.08 0.76 2.10 0.38 6.20 150.00
2C 24 41/0.08 0.76 2.20 0.38 6.40 94.20
2C 22 65/0.08 0.76 2.40 0.38 6.80 59.40
2C 20 104/0.08 0.76 2.50 0.38 7.20 36.70
2C 18 164/0.08 0.76 2.80 0.38 7.80 23.20
2C 16 265/0.08 0.76 3.10 0.38 10.00 14.60
3C 30 11/0.08 0.76 1.90 0.38 7.70 381.00
3C 28 16/0.08 0.76 2.00 0.38 7.90 239.00
3C 26 26/0.08 0.76 2.10 0.38 8.10 150.00
3C 24 41/0.08 0.76 2.20 0.38 8.30 94.20
3C 22 65/0.08 0.76 2.40 0.38 8.70 59.40
3C 20 104/0.08 0.76 2.50 0.38 9.20 36.70
3C 18 164/0.08 0.76 2.80 0.38 9.80 23.20
4C 30 11/0.08 0.76 1.90 0.38 7.90 381.00
4C 28 16/0.08 0.76 2.00 0.38 8.10 239.00
4C 26 26/0.08 0.76 2.10 0.38 8.40 150.00
4C 24 41/0.08 0.76 2.20 0.38 8.70 94.20
4C 22 65/0.08 0.76 2.40 0.38 9.10 59.40
4C 20 104/0.08 0.76 2.50 0.38 9.70 36.70
5C 30 11/0.08 0.76 1.90 0.38 8.20 381.00
5C 28 16/0.08 0.76 2.00 0.38 8.50 239.00
5C 26 26/0.08 0.76 2.10 0.38 8.60 150.00
5C 24 41/0.08 0.76 2.20 0.38 9.00 94.20
5C 22 65/0.08 0.76 2.40 0.38 9.60 59.40
6C 30 11/0.08 0.76 1.90 0.38 8.60 381.00
6C 28 16/0.08 0.76 2.00 0.38 8.90 239.00
6C 26 26/0.08 0.76 2.10 0.38 9.20 150.00
6C 24 41/0.08 0.76 2.20 0.38 9.50 94.20
