UL PVC Cable, AWM Style UL22181 20AWG 4C VW-1 80°C 30V, PVC / PVC

Product Categories

WCH Cable Industrial Co., Ltd.

Contact Now

Name: UL PVC Cable AWM Style UL22181 20AWG 4C VW1 80C 30V PVC PVC
Brand: WCH Cable
Price: 0.10 USD

Brand Name : WCH Cable

Model Number : UL22181

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 3050 meters

Price : USD0.10 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000,000 meters per week

Delivery Time : 9 days for ready goods

Packaging Details : 305 meters per reel

Style Number : UL22181

Conductor Material : Highly pure copper wire

Rated Temperature : 80°C

Insulation Material : Polyvinyl Chloride PVC

Rated Voltage : 30V

Sheath Material : Polyvinyl Chloride PVC

Application : Data Control Wiring

Contact Now

UL PVC Cable, AWM Style UL22181 20AWG 4C VW-1 80°C 30V, PVC / PVC

Conductor size: 20AWG

Wire assembly: 4 cores.

Insulation color: Black, blue, brown, yellow/green.

Insulation material: PVC.

Shield: no shield.

Sheath color: Grey.

Sheath material: PVC

Sheath thickness: 0.31mm

Flammability: VW-1

Rated temperature: 80°C

Rated voltage: 30V

Conductor resistance: 38.1Ω/km

Insulation resistance: 10mΩ/km

Recommended application: data control wiring.

Applied standard: UL758, UL1581.

Remark: color of wires or sheath can be changed according to customer's requirement.
